WIPCOOL PT-25V Siphon

Wipcool PT-25V - Innovative dry vertical siphon for air conditioning systems.

Provide your air conditioning system with reliable protection and hygiene with the Wipcool PT-25V, a state-of-the-art vertical spring-valve siphon. This smart, compact solution is ideal for systems with heat exchangers, offering full control over condensate drainage and an effective barrier to odors and insects.

Key advantages of the Wipcool PT-25V:

•     High-sensitivity spring-loaded valve - automatically opens when exposed to condensate and closes in the absence of condensate, protecting the system from outside contamination.
•     Easy snap-on installation - no specialized tools, quick maintenance.
•     Protection from odors and insects - the design allows water to be stored, creating an effective barrier.
•     High tightness - built-in gasket ensures full airtightness and no leakage.
•     Resistance to outdoor conditions - made of durable PC plastic, resistant to UV radiation and corrosion.

PT-25V is an ideal choice for vertical installations in modern HVAC systems - it provides reliability, cleanliness and durability, while being easy to use and aesthetically pleasing.

Technical specifications - Wipcool PT-25V

•     Manufacturer: Wipcool
•     Product code: PT-25V
•     Weight (gross): 0.080 kg
•     Operating vacuum: 1200 Pa
•     Dimensions of the device:

•         Length: 10 cm
•         Width: 6 cm
•         Height: 10 cm

•     Outer diameter: Ø32 mm
•     Inner diameter: Ø25 mm

Choose Wipcool PT-25V and bet on a smart solution that protects your installation all year round - without compromise.
